Security Mode Feature Set

SECURITY SET PASSWORD (F1h)

This command set user password or master password. The host outputs sector data with PIO data-out protocol to indicate

the information defined in the following table.

Security set Password data content1

Word

Content

Control word

Bit 0

Bits 1-7

Bit 8

Bits 9-15

Identifier

Reserved

Master Password Capability

Reserved

0=set user password

1=set master password

0=High

1=Maximum

1-16

Password (32 bytes)

Master Password Identifier. This word is valid if word 0 bit 0is set to one.

18-255

Reserved

SECURITY UNLOCK (F2h)

This command disables LOCKED MODE of the device. This command transfers 512 bytes of data from the host with PIO

data-out protocol. The following table defines the content of this information

Security Unlock information2

Word

Content

Control word

Bit 0

Bits 1-15

Identifier

Reserved

0=compare user password

1=compare master password

1-16

Password (32 bytes)

17-255

Reserved
